CS0505U

Image is for reference, please contact us to get the real picture

Manufacturer Part
CS0505U
Manufacturer
CUI Devices
Description
CURRENT SENSOR, OPEN LOOP, 3 A,
Category
Sensors, Transducers
Family
Current Sensors
Series
-
In Stock
30
Datasheets
-

CS0505U Specifications

  • Series:CSXX05U
  • Package:Tray
  • Part Status:Active
  • For Measuring:AC
  • Sensor Type:Open Loop
  • Current - Sensing:5A
  • Number of Channels:1
  • Output:Ratiometric, Voltage
  • Sensitivity:-
  • Frequency:DC ~ 40kHz
  • Linearity:±0.5%
  • Accuracy:±4.2%
  • Voltage - Supply:4.75V ~ 5.25V
  • Response Time:7µs
  • Current - Supply (Max):25mA
  • Operating Temperature:-10°C ~ 75°C
  • Polarization:Unidirectional
  • Mounting Type:Through Hole
  • Package / Case:Module
  • Supplier Device Package:-
