3609-2-07-21-00-00-08-0

Image is for reference, please contact us to get the real picture

Manufacturer Part
3609-2-07-21-00-00-08-0
Manufacturer
Mill-Max
Description
CONN PC PIN CIRC 0.080DIA GOLD
Category
Connectors, Interconnects
Family
Terminals - PC Pin, Single Post Connectors
Series
-
In Stock
1758
Datasheets
-

3609-2-07-21-00-00-08-0 Specifications

  • Series:3609
  • Package:Bulk
  • Part Status:Active
  • Terminal Type:PC Pin
  • Terminal Style:Wire
  • Pin Size - Above Flange:0.080" (2.03mm) Dia
  • Pin Size - Below Flange:0.103" (2.62mm) Dia
  • Length - Above Flange:0.375" (9.53mm)
  • Length - Below Flange:0.250" (6.35mm)
  • Length - Overall:0.671" (17.04mm)
  • Flange Diameter:0.142" (3.61mm)
  • Mounting Hole Diameter:-
  • Mounting Type:Free Hanging (In-Line)
  • Termination:Crimp
  • Insulation:Non-Insulated
  • Board Thickness:-
  • Contact Material:Brass Alloy
  • Contact Finish:Gold
  • Contact Finish Thickness:20.0µin (0.51µm)
