6170-0-00-15-00-00-03-0

Image is for reference, please contact us to get the real picture

Manufacturer Part
6170-0-00-15-00-00-03-0
Manufacturer
Mill-Max
Description
.320" LONG NAIL HEAD PIN
Category
Connectors, Interconnects
Family
Terminals - PC Pin, Single Post Connectors
Series
-
In Stock
6822
Datasheets
-

6170-0-00-15-00-00-03-0 Specifications

  • Series:6170
  • Package:Bulk
  • Part Status:Active
  • Terminal Type:PC Pin
  • Terminal Style:Single End, Nail Head
  • Pin Size - Above Flange:0.025" (0.64mm) Dia
  • Pin Size - Below Flange:-
  • Length - Above Flange:0.295" (7.49mm)
  • Length - Below Flange:-
  • Length - Overall:0.320" (8.13mm)
  • Flange Diameter:0.065" (1.65mm)
  • Mounting Hole Diameter:0.029" (0.74mm)
  • Mounting Type:Through Hole
  • Termination:Solder
  • Insulation:Non-Insulated
  • Board Thickness:-
  • Contact Material:Brass Alloy
  • Contact Finish:Gold
  • Contact Finish Thickness:10.0µin (0.25µm)
