0444752421

Image is for reference, please contact us to get the real picture

Manufacturer Part
0444752421
Manufacturer
Woodhead - Molex
Description
CONN RCPT 24POS 0.165 TIN PCB
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
1327
Datasheets
-

0444752421 Specifications

  • Series:Mini-Fit HCS 44475
  • Package:Tray
  • Part Status:Active
  • Connector Type:Receptacle
  • Contact Type:Female Socket
  • Style:Board to Board or Cable
  • Number of Positions:24
  • Number of Positions Loaded:All
  • Pitch - Mating:0.165" (4.20mm)
  • Number of Rows:2
  • Row Spacing - Mating:0.165" (4.20mm)
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Insulation Color:Natural
  • Insulation Height:0.446" (11.33mm)
  • Contact Length - Post:0.138" (3.50mm)
  • Operating Temperature:-40°C ~ 105°C
  • Material Flammability Rating:UL94 V-0
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:10.9mm, 15.24mm, 15.82mm
  • Ingress Protection:-
  • Features:Board Lock
  • Current Rating (Amps):-
  • Voltage Rating:600VAC
