M50-3151542

Image is for reference, please contact us to get the real picture

Manufacturer Part
M50-3151542
Manufacturer
Harwin
Description
CONN RCPT 30POS 0.05 GOLD SMD
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
1726
Datasheets
-

M50-3151542 Specifications

  • Series:Archer M50
  • Package:Tube
  • Part Status:Active
  • Connector Type:Receptacle, Bottom or Top Entry
  • Contact Type:Female Socket
  • Style:Board to Board or Cable
  • Number of Positions:30
  • Number of Positions Loaded:All
  • Pitch - Mating:0.050" (1.27mm)
  • Number of Rows:2
  • Row Spacing - Mating:0.050" (1.27mm)
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:Flash
  • Insulation Color:Black
  • Insulation Height:0.087" (2.20mm)
  • Contact Length - Post:-
  • Operating Temperature:-40°C ~ 105°C
  • Material Flammability Rating:UL94 V-0
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:3.2mm, 3.9mm, 4.6mm, 5.3mm, 7.2mm, 8.6mm
  • Ingress Protection:-
  • Features:Board Guide
  • Current Rating (Amps):1A
  • Voltage Rating:-
