B04P-VL

Image is for reference, please contact us to get the real picture

Manufacturer Part
B04P-VL
Manufacturer
JST
Description
CONN HEADER VERT 4POS 6.2MM
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Male Pins
Series
-
In Stock
2793
Datasheets
-

B04P-VL Specifications

  • Series:VL
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.244" (6.20mm)
  • Number of Positions:4
  • Number of Rows:2
  • Row Spacing - Mating:0.326" (8.28mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Latch Holder
  • Contact Length - Mating:-
  • Contact Length - Post:0.142" (3.60mm)
  • Overall Contact Length:-
  • Insulation Height:0.646" (16.40mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Polyamide (PA66), Nylon 6/6
  • Features:-
  • Operating Temperature:-25°C ~ 90°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Natural
  • Current Rating (Amps):20A
  • Voltage Rating:600V
