1720650002

Image is for reference, please contact us to get the real picture

Manufacturer Part
1720650002
Manufacturer
Woodhead - Molex
Description
CONN HEADER VERT 2POS
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Male Pins
Series
-
In Stock
1578
Datasheets
-

1720650002 Specifications

  • Series:Mega-Fit
  • Package:Tray
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:-
  • Number of Positions:2
  • Number of Rows:2
  • Row Spacing - Mating:0.224" (5.70mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:-
  • Contact Length - Post:0.147" (3.73mm)
  • Overall Contact Length:-
  • Insulation Height:0.583" (14.80mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper
  • Insulation Material:Liquid Crystal Polymer (LCP)
  • Features:Board Guide, Glow Wire Compliant
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-
