2035551114

Image is for reference, please contact us to get the real picture

Manufacturer Part
2035551114
Manufacturer
Woodhead - Molex
Description
CP65 WTB HDR RA TH 0 BLK 4CKT
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Male Pins
Series
-
In Stock
865
Datasheets
-

2035551114 Specifications

  • Series:CP-6.5 203555
  • Package:Tube
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Tab
  • Pitch - Mating:0.256" (6.50mm)
  • Number of Positions:4
  • Number of Rows:2
  • Row Spacing - Mating:0.256" (6.50mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Latch Holder
  • Contact Length - Mating:-
  • Contact Length - Post:0.150" (3.81mm)
  • Overall Contact Length:-
  • Insulation Height:0.598" (15.19mm)
  • Contact Shape:Rectangular
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Polyamide (PA), Nylon
  • Features:Board Guide, Solder Retention
  • Operating Temperature:-40°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Blue
  • Current Rating (Amps):Varies by Wire Gauge
  • Voltage Rating:600VAC/DC
