UG1JPL-TP

Image is for reference, please contact us to get the real picture

Manufacturer Part
UG1JPL-TP
Manufacturer
Micro Commercial Components (MCC)
Description
ULTRAFAST RECTIFIERS 600V 1A SOD
Category
Discrete Semiconductor Products
Family
Diodes - Rectifiers - Single
Series
-
In Stock
4960
Datasheets
-

UG1JPL-TP Specifications

  • Series:-
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Diode Type:Standard
  • Voltage - DC Reverse (Vr) (Max):600 V
  • Current - Average Rectified (Io):1A
  • Voltage - Forward (Vf) (Max) @ If:1.7 V @ 1 A
  • Speed:Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr):35 ns
  • Current - Reverse Leakage @ Vr:5 µA @ 600 V
  • Capacitance @ Vr, F:-
  • Mounting Type:Surface Mount
  • Package / Case:SOD-123F
  • Supplier Device Package:SOD-123FL
  • Operating Temperature - Junction:-55°C ~ 150°C
