HS1MAL M3G

Image is for reference, please contact us to get the real picture

Manufacturer Part
HS1MAL M3G
Manufacturer
TSC (Taiwan Semiconductor)
Description
75NS, 1A, 1000V, HIGH EFFICIENT
Category
Discrete Semiconductor Products
Family
Diodes - Rectifiers - Single
Series
-
In Stock
6950
Datasheets
-

HS1MAL M3G Specifications

  • Series:-
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Diode Type:Standard
  • Voltage - DC Reverse (Vr) (Max):1000 V
  • Current - Average Rectified (Io):1A
  • Voltage - Forward (Vf) (Max) @ If:1.7 V @ 1 A
  • Speed:Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr):75 ns
  • Current - Reverse Leakage @ Vr:1 µA @ 1000 V
  • Capacitance @ Vr, F:8pF @ 4V, 1MHz
  • Mounting Type:Surface Mount
  • Package / Case:DO-221AC, SMA Flat Leads
  • Supplier Device Package:Thin SMA
  • Operating Temperature - Junction:-55°C ~ 150°C
