SPD08P06PGBTMA1 Specifications

• Series:SIPMOS®
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:8.83A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):6.2V
• Rds On (Max) @ Id, Vgs:300mOhm @ 10A, 6.2V
• Vgs(th) (Max) @ Id:4V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:13 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:420 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):42W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PG-TO252-3
• Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
