CSD13302W Specifications

• Series:NexFET™
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):12 V
• Current - Continuous Drain (Id) @ 25°C:1.6A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
• Rds On (Max) @ Id, Vgs:17.1mOhm @ 1A, 4.5V
• Vgs(th) (Max) @ Id:1.3V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:7.8 nC @ 4.5 V
• Vgs (Max):±10V
• Input Capacitance (Ciss) (Max) @ Vds:862 pF @ 6 V
• FET Feature:-
• Power Dissipation (Max):1.8W (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:4-DSBGA
• Package / Case:4-UFBGA, DSBGA
