NMSD200B01-7 Specifications

• Series:-
• Package:Tape & Reel (TR)Tape & Reel (TR)Cut Tape (CT)Cut Tape (CT)
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:200mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):5V, 10V
• Rds On (Max) @ Id, Vgs:3Ohm @ 50mA, 5V
• Vgs(th) (Max) @ Id:3V @ 1mA
• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:50 pF @ 25 V
• FET Feature:Schottky Diode (Isolated)
• Power Dissipation (Max):200mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:SOT-363
• Package / Case:6-TSSOP, SC-88, SOT-363
