M2024S3A2A30

Image is for reference, please contact us to get the real picture

Manufacturer Part
M2024S3A2A30
Manufacturer
NKK Switches
Description
SWITCH TOGGLE SP3T 6A 125V
Category
Switches
Family
Toggle Switches
Series
-
In Stock
4642
Datasheets
-

M2024S3A2A30 Specifications

  • Series:M
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Through Hole, Right Angle
  • Circuit:SP3T
  • Switch Function:On-On-On
  • Current Rating (Amps):6A (AC), 3A (DC)
  • Voltage Rating - AC:125 V
  • Voltage Rating - DC:30 V
  • Actuator Type:Standard Round
  • Actuator Length:8.28mm
  • Illumination:Non-Illuminated
  • Illumination Type, Color:-
  • Illumination Voltage (Nominal):-
  • Termination Style:PC Pin
  • Panel Cutout Dimensions:-
  • Bushing Thread:Unthreaded
  • Ingress Protection:-
  • Features:Jumper needed to achieve triple throw
  • Operating Temperature:-30°C ~ 85°C
