JL15SKSBDP2

Image is for reference, please contact us to get the real picture

Manufacturer Part
JL15SKSBDP2
Manufacturer
NKK Switches
Description
SWITCH TACTILE SPST-NO 0.05A 24V
Category
Switches
Family
Tactile Switches
Series
-
In Stock
17
Datasheets
-

JL15SKSBDP2 Specifications

  • Series:JL
  • Package:Tray
  • Part Status:Active
  • Circuit:SPST-NO
  • Switch Function:Off-Mom
  • Contact Rating @ Voltage:0.05A @ 24VDC
  • Actuator Type:Square Button
  • Mounting Type:Through Hole
  • Actuator Height off PCB, Vertical:7.85mm
  • Actuator Length, Right Angle:-
  • Actuator Orientation:Top Actuated
  • Termination Style:PC Pin
  • Outline:22.00mm x 22.00mm
  • Illumination:Illuminated
  • Illumination Type, Color:LED, Amber
  • Illumination Voltage (Nominal):4 VDC
  • Operating Force:300gf
  • Ingress Protection:-
  • Features:-
  • Operating Temperature:-25°C ~ 50°C
