T9GS2L24-22

Image is for reference, please contact us to get the real picture

Manufacturer Part
T9GS2L24-22
Manufacturer
TE Connectivity Potter & Brumfield Relays
Description
RELAY GEN PURPOSE SPST 20A 22V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
409
Datasheets
-

T9GS2L24-22 Specifications

  • Series:T9G
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:22VDC
  • Contact Form:SPST-NC (1 Form B)
  • Contact Rating (Current):20 A
  • Switching Voltage:480VAC - Max
  • Coil Current:41 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin, Quick Connect - 0.250" (6.3mm)
  • Seal Rating:Sealed - Fully
  • Coil Insulation:Class F
  • Must Operate Voltage:16.5 VDC
  • Must Release Voltage:2.2 VDC
  • Operate Time:15 ms
  • Release Time:22 ms
  • Operating Temperature:-40°C ~ 105°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
