ALE1PB24

Image is for reference, please contact us to get the real picture

Manufacturer Part
ALE1PB24
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE SPST 16A 24V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
65
Datasheets
-

ALE1PB24 Specifications

  • Series:ALE
  • Package:Bulk
  • Part Status:Not For New Designs
  • Mounting Type:Through Hole
  • Coil Voltage:24VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):16 A
  • Switching Voltage:277VAC - Max
  • Coil Current:16.7 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:-
  • Coil Insulation:Class B
  • Must Operate Voltage:18 VDC
  • Must Release Voltage:1.2 VDC
  • Operate Time:20 ms
  • Release Time:20 ms
  • Operating Temperature:-40°C ~ 85°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
