JS1AF-F-5V-F

Image is for reference, please contact us to get the real picture

Manufacturer Part
JS1AF-F-5V-F
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE SPST 10A 5V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
64
Datasheets
-

JS1AF-F-5V-F Specifications

  • Series:JS
  • Package:Bulk
  • Part Status:Not For New Designs
  • Mounting Type:Through Hole
  • Coil Voltage:5VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):10 A
  • Switching Voltage:250VAC, 100VDC - Max
  • Coil Current:72 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Flux Protection
  • Coil Insulation:Class F
  • Must Operate Voltage:3.5 VDC
  • Must Release Voltage:0.5 VDC
  • Operate Time:10 ms
  • Release Time:10 ms
  • Operating Temperature:-40°C ~ 105°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
