ADW1203HT

Image is for reference, please contact us to get the real picture

Manufacturer Part
ADW1203HT
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE SPST 16A 3V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
81
Datasheets
-

ADW1203HT Specifications

  • Series:DW-H
  • Package:Tube
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:3VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):16 A
  • Switching Voltage:277VAC - Max
  • Coil Current:133 mA
  • Coil Type:Latching, Dual Coil
  • Features:IEC Compliant
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Flux Protection
  • Coil Insulation:Class F
  • Must Operate Voltage:2.4 VDC
  • Must Release Voltage:-
  • Operate Time:15 ms
  • Release Time:15 ms
  • Operating Temperature:-40°C ~ 85°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
