1220050000

Image is for reference, please contact us to get the real picture

Manufacturer Part
1220050000
Manufacturer
Weidmuller
Description
DRH275024LT
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
1010
Datasheets
-

1220050000 Specifications

  • Series:DRH
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Socketable
  • Coil Voltage:24VDC
  • Contact Form:DPST-NO/NC (1 Form A, 1 Form B)
  • Contact Rating (Current):16 A
  • Switching Voltage:250VAC, 300VDC - Max
  • Coil Current:60 mA
  • Coil Type:Non Latching
  • Features:Lighted Indicator, Test Button
  • Termination Style:Plug In, Quick Connect - 0.187" (4.7mm)
  • Seal Rating:-
  • Coil Insulation:-
  • Must Operate Voltage:18 VDC
  • Must Release Voltage:2.4 VDC
  • Operate Time:20 ms
  • Release Time:20 ms
  • Operating Temperature:-40°C ~ 60°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
