ADW1109HLW

Image is for reference, please contact us to get the real picture

Manufacturer Part
ADW1109HLW
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE SPST 16A 9V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
96
Datasheets
-

ADW1109HLW Specifications

  • Series:DW-H
  • Package:Tray
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:9VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):16 A
  • Switching Voltage:277VAC - Max
  • Coil Current:22.2 mA
  • Coil Type:Latching, Single Coil
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Flux Protection
  • Coil Insulation:Class F
  • Must Operate Voltage:7.2 VDC
  • Must Release Voltage:-
  • Operate Time:15 ms
  • Release Time:15 ms
  • Operating Temperature:-40°C ~ 85°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
