HE2AN-AC24V

Image is for reference, please contact us to get the real picture

Manufacturer Part
HE2AN-AC24V
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE DPST 25A 24V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
20
Datasheets
-

HE2AN-AC24V Specifications

  • Series:HE
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Chassis Mount
  • Coil Voltage:24VAC
  • Contact Form:DPST-NO (2 Form A)
  • Contact Rating (Current):25 A
  • Switching Voltage:277VAC, 30VDC - Max
  • Coil Current:74 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:Plug In, Quick Connect - 0.250" (6.3mm)
  • Seal Rating:-
  • Coil Insulation:-
  • Must Operate Voltage:16.8 VAC
  • Must Release Voltage:3.6 VAC
  • Operate Time:30 ms
  • Release Time:30 ms
  • Operating Temperature:-50°C ~ 55°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
