ESDLC12VD3B-TP

Image is for reference, please contact us to get the real picture

Manufacturer Part
ESDLC12VD3B-TP
Manufacturer
Micro Commercial Components (MCC)
Description
TVS DIODE 12V 28.6V SOD323
Category
Circuit Protection Devices
Family
TVS - Diodes
Series
-
In Stock
6751
Datasheets
-

ESDLC12VD3B-TP Specifications

  • Series:-
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Type:Zener
  • Unidirectional Channels:-
  • Bidirectional Channels:1
  • Voltage - Reverse Standoff (Typ):12V
  • Voltage - Breakdown (Min):13.3V
  • Voltage - Clamping (Max) @ Ipp:28.6V
  • Current - Peak Pulse (10/1000µs):11A (8/20µs)
  • Power - Peak Pulse:350W
  • Power Line Protection:No
  • Applications:General Purpose
  • Capacitance @ Frequency:3pF @ 1MHz
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Surface Mount
  • Package / Case:SC-76, SOD-323
  • Supplier Device Package:SOD-323
