SZ1SMA70AT3G

Image is for reference, please contact us to get the real picture

Manufacturer Part
SZ1SMA70AT3G
Manufacturer
Wickmann / Littelfuse
Description
TVS DIODE 70V 113V SMA
Category
Circuit Protection Devices
Family
TVS - Diodes
Series
-
In Stock
2281
Datasheets
-

SZ1SMA70AT3G Specifications

  • Series:Automotive, AEC-Q101
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Type:Zener
  • Unidirectional Channels:1
  • Bidirectional Channels:-
  • Voltage - Reverse Standoff (Typ):70V
  • Voltage - Breakdown (Min):77.8V
  • Voltage - Clamping (Max) @ Ipp:113V
  • Current - Peak Pulse (10/1000µs):3.5A
  • Power - Peak Pulse:400W
  • Power Line Protection:No
  • Applications:Automotive
  • Capacitance @ Frequency:190pF @ 1MHz
  • Operating Temperature:-65°C ~ 150°C (TJ)
  • Mounting Type:Surface Mount
  • Package / Case:DO-214AC, SMA
  • Supplier Device Package:SMA
