ELG-100U-24B

Image is for reference, please contact us to get the real picture

Manufacturer Part
ELG-100U-24B
Manufacturer
MEAN WELL
Description
LED DRVR CC/CV AC/DC
Category
Power Supplies - External/Internal (Off-Board)
Family
LED Drivers
Series
-
In Stock
21
Datasheets
-

ELG-100U-24B Specifications

  • Series:ELG-100U (100W)
  • Package:Bulk
  • Part Status:Active
  • Type:Constant Current, Voltage
  • Topology:AC DC Converter
  • Number of Outputs:1
  • Voltage - Input (Min):100VAC
  • Voltage - Input (Max):305VAC
  • Voltage - Output:24V
  • Current - Output (Max):4A
  • Power (Watts):96 W
  • Voltage - Isolation:3.75 kV
  • Dimming:Analog, PWM
  • Features:OCP, OTP, OVP, SCP
  • Ratings:NEMA 410
  • Operating Temperature:-40°C ~ 85°C
  • Efficiency:88%
  • Termination Style:Wire Leads
  • Size / Dimension:6.89" L x 2.48" W x 1.40" H (175.0mm x 63.0mm x 35.5mm)
  • Approval Agency:cURus, FCC
  • Standard Number:-
