CUS400M-48/BX5 Specifications

• Series:CUS400M (400W)
• Package:Box
• Part Status:Active
• Type:Open Frame
• Number of Outputs:1
• Voltage - Input:85 ~ 264 VAC
• Voltage - Output 1:48V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):5.21A
• Power (Watts):250W (400W Forced Air)
• Applications:ITE (Commercial), Medical
• Voltage - Isolation:4 kV
• Efficiency:-
• Operating Temperature:-20°C ~ 70°C (With Derating)
• Features:Adjustable Output, Baseplate, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:5.57" L x 3.36" W x 1.61" H (141.6mm x 85.3mm x 40.8mm)
• Approval Agency:CE
• Standard Number:60601-1; 62368-1
