ABC600-1012G Specifications

• Series:ABC600 (600W)
• Package:Box
• Part Status:Active
• Type:Open Frame
• Number of Outputs:1
• Voltage - Input:90 ~ 277 VAC
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):50A
• Power (Watts):420W (600W Forced Air)
• Applications:ITE (Commercial)
• Voltage - Isolation:4.242 kV
• Efficiency:94%
• Operating Temperature:-25°C ~ 70°C (With Derating)
• Features:Adjustable Output, Load Sharing, PFC, PMBus™ Interface, Remote On/Off, Remote Sense, Standby Output, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:8.00" L x 5.00" W x 1.60" H (203.2mm x 127.0mm x 40.6mm)
• Approval Agency:CE
• Standard Number:-
