LDT2400-72 Specifications

• Series:LDT2400 (2400W)
• Package:Box
• Part Status:Active
• Type:Enclosed
• Number of Outputs:1
• Voltage - Input:340 ~ 550 VAC (3 Phase)
• Voltage - Output 1:72V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):33A
• Power (Watts):2400W
• Applications:ITE (Commercial)
• Voltage - Isolation:4.2 kV
• Efficiency:93%
• Operating Temperature:-40°C ~ 70°C (With Derating)
• Features:Adjustable Output, DC Input Capable, IP20, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output
• Mounting Type:DIN Rail
• Size / Dimension:3.98" L x 9.17" W x 6.30" H (101.0mm x 233.0mm x 160.0mm)
• Approval Agency:-
• Standard Number:-
