ECL30UD01-T

Image is for reference, please contact us to get the real picture

Manufacturer Part
ECL30UD01-T
Manufacturer
XP Power
Description
AC/DC CONVERTER +/-12V 30W
Category
Power Supplies - External/Internal (Off-Board)
Family
AC DC Converters
Series
-
In Stock
20
Datasheets
-

ECL30UD01-T Specifications

  • Series:ECL (30W)
  • Package:Box
  • Part Status:Active
  • Type:Open Frame
  • Number of Outputs:2
  • Voltage - Input:85 ~ 264 VAC
  • Voltage - Output 1:12V
  • Voltage - Output 2:-12V
  • Voltage - Output 3:-
  • Voltage - Output 4:-
  • Current - Output (Max):1.3A, 1.3A
  • Power (Watts):30W
  • Applications:ITE (Commercial)
  • Voltage - Isolation:3 kV
  • Efficiency:84%
  • Operating Temperature:-20°C ~ 70°C (With Derating)
  • Features:Adjustable Output, DC Input Capable, Universal Input
  • Mounting Type:Chassis Mount
  • Size / Dimension:3.46" L x 1.36" W x 0.88" H (87.9mm x 34.6mm x 22.4mm)
  • Approval Agency:-
  • Standard Number:62368-1
