PQU650-54 Specifications

• Series:PQU650 (650W)
• Package:Box
• Part Status:Active
• Type:Open Frame
• Number of Outputs:1
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output 1:54V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):12.1A
• Power (Watts):653W
• Applications:ITE (Commercial), Medical
• Voltage - Isolation:4 kV
• Efficiency:95%
• Operating Temperature:-30°C ~ 70°C (With Derating)
• Features:Adjustable Output, Load Sharing, Remote Sense, Standby Output, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:6.00" L x 4.00" W x 1.57" H (152.4mm x 101.6mm x 40.0mm)
• Approval Agency:CB, CCC, cCSAus, CE, cTUVus, TUV
• Standard Number:-
