CFM500M480 Specifications

• Series:CFM500M (500W)
• Package:Box
• Part Status:Active
• Type:Open Frame
• Number of Outputs:1
• Voltage - Input:85 ~ 264 VAC
• Voltage - Output 1:48V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):6.67A
• Power (Watts):320W (500W Forced Air)
• Applications:Household Appliances, Medical
• Voltage - Isolation:4 kV
• Efficiency:94%
• Operating Temperature:-30°C ~ 85°C (With Derating)
• Features:Adjustable Output, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:5.00" L x 3.00" W x 1.54" H (127.0mm x 76.2mm x 39.1mm)
• Approval Agency:ANSI/AAMI, ES, IEC
• Standard Number:60335-1; 60601-1
