GST90A48-P1M Specifications

• Series:GST90A (90W)
• Package:Box
• Part Status:Active
• Region Utilized:International
• Form:Desktop (Class I)
• Input Type:Cord (Sold Separately)
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:48V
• Current - Output (Max):1.87A
• Power (Watts):90 W
• No Load Power Consumption:150mW (Max)
• Polarization:Positive Center
• Applications:ITE (Commercial)
• Efficiency:Level VI
• Operating Temperature:-30°C ~ 70°C
• Output Connector:Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 11.0mm
• Cord Length:47.2" (1.20m)
• Input Connector:IEC 320-C14
• Size / Dimension:5.71" L x 2.36" W x 1.26" H (145.0mm x 60.0mm x 32.0mm)
• Approval Agency:BIS, BSMI, CB, CCC, CE, cULus, EAC, GS, KC, PSE, RCM, SIRIM
• Standard Number:-
