TR9KI5000LCP-IM(R6B) Specifications

• Series:GTM961200P120VV.V-T2
• Package:Bulk
• Part Status:Active
• Region Utilized:International
• Form:Desktop (Class II)
• Input Type:Cord (Sold Separately)
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:24V
• Current - Output (Max):5A
• Power (Watts):120 W
• No Load Power Consumption:150mW (Max)
• Polarization:Positive Center
• Applications:Household Appliances, ITE (Commercial), Medical
• Efficiency:Level VI
• Operating Temperature:-20°C ~ 40°C
• Output Connector:Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 11.0mm
• Cord Length:47.2" (1.20m)
• Input Connector:IEC 320-C8
• Size / Dimension:5.88" L x 2.47" W x 1.34" H (149.3mm x 62.8mm x 34.0mm)
• Approval Agency:CB, CCC, CE, EAC, ETL, PSE, RCM, S-Mark, UKRSepro, VCCI
• Standard Number:60335-1; 60601-1-11; 60601-1-2; 60950-1; 61347-1; 62368-1
