PM3604-150-RC

Image is for reference, please contact us to get the real picture

Manufacturer Part
PM3604-150-RC
Manufacturer
J.W. Miller / Bourns
Description
INDUCT ARRAY 2 COIL 150UH SMD
Category
Inductors, Coils, Chokes
Family
Arrays, Signal Transformers
Series
-
In Stock
1023
Datasheets
-

PM3604-150-RC Specifications

  • Series:PM3600
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Number of Coils:2
  • Inductance - Connected In Parallel:150 µH
  • Inductance - Connected In Series:600 µH
  • Tolerance:±20%
  • Current Rating - Parallel:780 mA
  • Current Rating - Series:390 mA
  • Current Saturation - Parallel:-
  • Current Saturation - Series:-
  • DC Resistance (DCR) - Parallel:320mOhm Max
  • DC Resistance (DCR) - Series:1.28Ohm Max
  • Shielding:Unshielded
  • Ratings:-
  • Operating Temperature:-55°C ~ 125°C
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Size / Dimension:0.550" L x 0.452" W (13.97mm x 11.48mm)
  • Height:0.265" (6.73mm)
