EEF-FD0K220R Specifications

• Series:SP-Cap FD
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Polymer
• Capacitance:22 µF
• Tolerance:±20%
• Voltage - Rated:8 V
• ESR (Equivalent Series Resistance):28mOhm
• Lifetime @ Temp.:1000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Ratings:-
• Applications:General Purpose
• Ripple Current @ Low Frequency:-
• Ripple Current @ High Frequency:2 A @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.287" L x 0.169" W (7.30mm x 4.30mm)
• Height - Seated (Max):0.047" (1.20mm)
• Surface Mount Land Size:0.287" L x 0.169" W (7.30mm x 4.30mm)
• Mounting Type:Surface Mount
• Package / Case:2917 (7343 Metric)
