107SML063M Specifications

• Series:SML
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Capacitance:100 µF
• Tolerance:±20%
• Voltage - Rated:63 V
• ESR (Equivalent Series Resistance):1.99Ohm @ 120Hz
• Lifetime @ Temp.:2000 Hrs @ 85°C
• Operating Temperature:-40°C ~ 85°C
• Polarization:Polar
• Ratings:-
• Applications:General Purpose
• Ripple Current @ Low Frequency:280 mA @ 120 Hz
• Ripple Current @ High Frequency:420 mA @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.394" Dia (10.00mm)
• Height - Seated (Max):0.417" (10.60mm)
• Surface Mount Land Size:0.394" L x 0.394" W (10.00mm x 10.00mm)
• Mounting Type:Surface Mount
• Package / Case:Radial, Can - SMD
